Victron Orion 48V to 24V - 380W 16A Isolated DC/DC Converter (SKU Part Number ORI482441110)

Victron Orion DC/DC Converter: Reliable 48V to 24V Power Solution

The remote on/off eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or by for example the engine run/stop switch (see manual). All models are short circuit proof and can be paralleled to increase output current. An unlimited number of units can be connected in parallel.

Features

• IP43 protection
• When installed with the screw terminals oriented downwards
• Screw terminals
• No special tools needed for installation
• Input fuse - On 12V and 24V input models only

Specifications

• Type: Isolated
• Input Voltage Range: 40-70 V
• Under Voltage Shutdown: 28 V
• Under Voltage Restart: 30 V
• Output Voltage Adjust Range: 20-30 V
• Nominal Output Voltage: 24.2 V
• Output Voltage Tolerance: +/-0.2 V
• Output Noise: 2 mV rms
• Continuous Output Current at Nominal Output Voltage & 40°C: 16 A
• Maximum Output Current (10 s) at Nominal Output Voltage: 25 A
• Short-Circuit Output Current: 40 A
• Continuous Output Power at 25°C: 430 W
• Continuous Output Power at 40°C: 380 W
• Efficiency: 89%
• No Load Input Current: <80 mA
• Current Consumption: <200 uA When Disabled Via its Remote Port
• Galvanic Isolation: 200 VDC Between Input, Output & Case
• Operating Temperature: -20 to 55°C
• Humidity: Maximum 95% Non-Condensing
• DC Connection: Screw Terminals
• Maximum Cable Cross-Section: 16 mm² (6 AWG)
• Standards: EN 60950, EN 61000-6-3, EN 55014-1, EN 61000-6-2, EN 61000-6-1, EN 55014-2, ECE R10-5
• Dimensions: 5.1 in x 7.3 in x 2.8 in
• Weight: 4 lb

Documents

• Specification Sheet

• Instruction/Installation Manual

High-Efficiency Power Conversion

The Victron Orion DC/DC converter is designed to efficiently convert 48V input to a stable 24V output, providing up to 380W of continuous power. With a maximum current of 16A, this isolated converter ensures minimal energy loss, making it an excellent choice for powering 24V systems from higher-voltage battery banks. Its high efficiency reduces heat generation, which contributes to improved reliability and prolonged lifespan of your electrical system components. This product is ideal for applications in automotive, marine, and industrial power solutions.

Isolated DC/DC Converter for Enhanced Safety

This Victron Orion DC/DC converter features galvanic isolation, ensuring the input and output circuits remain electrically separate. This isolation protects sensitive electronics from voltage spikes and prevents ground loop issues, enhancing system safety and reliability. The design meets strict safety standards, making it suitable for critical power applications where reliable isolation is essential. Additionally, its rugged build withstands challenging environments, making it dependable even under harsh conditions.

Compact Design with Versatile Installation

With a compact and lightweight design, the Victron Orion DC/DC converter fits easily into tight spaces, simplifying installation in various setups. Its flexible mounting options and robust enclosure provide resistance against vibrations and mechanical shocks. This adaptability makes it suitable for use in vehicles, marine crafts, and renewable energy systems. Furthermore, its user-friendly interface allows for straightforward integration and maintenance, giving users confidence in their power conversion solution.
