Victron Lynx Distributor (M10) – Modular DC Busbar with Fuse Monitoring
Victron Lynx Distributor: Advanced Modular DC Power Management
The Victron Lynx Distributor is a modular DC busbar system with four fuse-protected connections and integrated fuse monitoring. It is part of the Victron Lynx modular system, which incorporates DC connections, distribution, fusing, battery monitoring, and Lithium battery management in a clean, expandable format.
Key Features
- Positive and negative busbars with 4 fuse-protected connections
- Fuse status monitoring with LED indicators for each fuse
- 1000A continuous DC current rating
- Modular design – connects with other Lynx modules (Lynx Power In, Lynx Smart BMS, Lynx Shunt)
- Supports 12V, 24V, and 48V systems
- M10 busbar connections for high-current applications
- Reverse polarity protection
- Compatible with Class-T and MEGA fuses
- BEP switch for improved safety
Technical Specifications
| Specification | Value |
|---|---|
| Part Number | LYN060102010 |
| Voltage Range | 9–60V DC |
| Supported System Voltages | 12V, 24V, 48V |
| Current Rating | 1000A DC continuous |
| Max Current Consumption | 100 mA (all LEDs lit) |
| Reverse Polarity Protection | Yes |
| Fuse Connections | 4 (positive busbar) |
| Busbar Connection Type | M10 |
| Protection Rating | IP22 |
| Dimensions (L×W×H) | 290 × 170 × 80 mm |
| Weight | 2.2 kg (4.9 lbs) |
Warranty
Victron Energy provides a 5-year limited warranty on this product.
Documentation
Innovative Design for Flexible Power Distribution
The Victron Lynx Distributor is a state-of-the-art modular DC busbar designed to offer flexible, scalable power distribution solutions. Its M10 connectors simplify installations by allowing multiple DC distribution points to be combined onto one compact and efficient system. The modular design enables easy expansion and customization, providing enhanced adaptability for various electrical systems, including marine, automotive, and renewable energy setups. This intelligent arrangement reduces wiring complexity while improving system safety and reliability.
Integrated Fuse Monitoring for Enhanced Safety
One of the standout features of the Victron Lynx Distributor is its built-in fuse monitoring capability. It actively monitors individual fuses connected to the busbar and alerts users to any faults or failures, ensuring system integrity and protecting connected equipment. This proactive safety feature minimizes downtime by enabling quick identification and replacement of blown fuses. Fuse monitoring also adds an extra layer of protection against electrical overloads, making it an essential component for critical power distribution applications.
Durability and High-Quality Construction
Constructed with premium materials, the Victron Lynx Distributor guarantees long-term durability even in demanding environments. The robust build resists corrosion and mechanical stress, making it ideal for use in harsh conditions typical in marine, industrial, and off-grid power applications. Its compact form factor accommodates tight spaces without compromising on performance. The use of high-quality components by Victron Energy ensures reliable electrical connections and safe operation, offering peace of mind to users requiring dependable DC power distribution solutions.
