Victron Energy BlueSolar MPPT 100/50

Victron Energy BlueSolar: Advanced MPPT 100/50 Solar Charge Controller

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, BlueSolar maximizes this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. BlueSolar maintains battery health, extending its life.

Features

• MPPT: Ultra fast maximum power point tracking by constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels and harvested for storage
• The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing
• Remote monitoring and control - remotely control and monitor the extensive features of your BlueSolar MPPT charger by attaching a bluetooth dongle and pairing it with your smartphone or other device via VictronConnect
• If your installation is connected to the internet with a GX device, the Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both VictronConnect and VRM are free to use
• For remote installations - even when there is no internet connection nearby - you may be able to monitor your MPPT by connecting the GlobalLink 520


Specifications

• Type: MPPT
• Series/Model: 100/50
• Battery Voltage: 12/24V Auto Select
• Enclosure Rating:
  • IP43 (electronic components)
  • IP22 (connection area)
• Maximum PV Open Circuit Voltage: 100 V
• Operating Temperature: -30 to 60°C (Full Rated Output up to 40°C)
• Self-Consumption:
  • 30 mA at 12 V
  • 20 mA at 24 V
• Humidity: 95%, Non-Condensing
• Power Terminal: 16 mm² / 6 AWG
• Temperature Compensation: -16 mV/-32 mV/°C
• Maximum PV Short Circuit Current: 60 A
• Nominal PV Power:
  • 12 V: 700 W
  • 24 V: 1400 W
• Charge Current Rating: 45 A
• Charging Stages:
  • Absorption Charge: 14.4/28.8 V (Adjustable)
  • Float Charge: 13.8/27.6 V (Adjustable)
• Peak Efficiency: 98%
• Charging Algorithm: Multi-Stage Adaptive
• Data Communication: VE.Direct
• Color: Blue (RAL 5012)
• Dimensions: 130 mm (H) x 186 mm (W) x 70 mm (D)
• Weight: 1.3 kg
• Standards Compliance:
  • EN/IEC 62109-1
  • UL 1741
  • CSA C22.2


Documents

• Specification Sheet
• Owners/User Manual
• Specification Sheet

Highly Efficient Maximum Power Point Tracking Technology

The Victron Energy BlueSolar MPPT 100/50 excels with its advanced Maximum Power Point Tracking (MPPT) technology, designed to maximize solar energy harvest. This technology continuously optimizes the match between solar panels and the battery system, increasing charging efficiency by up to 30% compared to traditional controllers. Its smart MPPT algorithms work efficiently even in less-than-ideal weather conditions, ensuring you get the most power possible from your solar setup. With a rated voltage of 100V and current handling of 50A, this controller is ideal for medium to large-sized solar systems.

Comprehensive Battery Management and Safety Features

Victron Energy BlueSolar MPPT 100/50 provides advanced battery management, ensuring the longevity and health of your battery bank. It supports multiple battery chemistries including lead-acid and lithium, with customizable charging profiles for optimal performance. Built-in protections against overcharging, deep discharge, short circuits, and reverse polarity add a layer of safety to your solar energy system. The integrated temperature sensor adjusts charging based on battery temperature, helping prevent damage and extending battery life in all environments.

Robust Build and User-Friendly Monitoring Options

This BlueSolar MPPT controller features a robust, corrosion-resistant aluminum case designed to withstand harsh outdoor conditions. Its compact design allows easy installation in solar setups of various sizes. Additionally, users can monitor system performance through Victron’s dedicated apps and remote management tools, compatible with Bluetooth and other communication interfaces. Real-time data on voltage, current, and system status makes it convenient to optimize and troubleshoot your solar energy system remotely.
