U5949-O-5T9-CDOT - 5 Term RNGLS Plain Top LVR Byps 1 MN BRKR Prov 5TH Term 9 Oclock Pos SGL Ped Dir Bury W-1-200 Amp MN T-Fuse Pullout CO Dot

The 5-Terminal RNGLS Meter Socket with Lever Bypass is a robust and utility-grade solution for underground metering applications. This model features a plain top design, a lever bypass (LVR Byps) mechanism, and is ringless (RNGLS), making it suitable for residential and light commercial use where easy access and bypass capability are required.

It comes provisioned for a main breaker (MN BRKR Prov) and includes a fifth terminal in the 9 o’clock position, supporting 120/208V network metering configurations. The unit is designed for single pedestal (SGL Ped) direct burial (Dir Bury) setups, making it ideal for underground service installations. With a W-1 rated 200 Amp continuous load capacity, this socket also includes a T-fuse pullout, providing additional safety and service disconnect options.

Finished in accordance with Colorado DOT (CO Dot) specifications, this socket is built for tough environments and long-lasting performance in public and utility installations.

Key Features:

• Meter Socket Type: Ringless (RNGLS)
• Terminals: 5-Terminal configuration with 5th terminal at 9 o’clock for network metering
• Bypass: Lever bypass (LVR Byps) for utility access
• Top Design: Plain top (no hub)
• Main Breaker Provision: Space allocated for field installation of a main breaker
• Service Type: Single pedestal (SGL Ped) for direct burial (Dir Bury)
• Amperage Rating: 200 Amp continuous (W-1 Rated)
• Fuse Type: Main T-fuse pullout for disconnect and overcurrent protection
• Compliance: Built to CO DOT standards
• Application: Suitable for underground service residential or light commercial metering

The 5-Term RNGLS Plain Top Lever Bypass Meter Socket offers a complete, field-ready solution for utility-grade metering with flexibility, security, and compliance in mind.

Documents:
Product Spec Sheet
