SPAN Smart Electrical Panel SPN-1-00800

Discover the Benefits of the SPAN Smart Electrical Panel

Monitoring and control for every circuit.

Feature Bullets

• Fully customizable backup when paired with storage
• Streamlined solar + storage installation
• Integrated feed-through lugs
• Intelligent grid disconnect via 200 A electronic relay
• Revenue accurate energy monitoring
• Indoor and outdoor rated
• Supports AC or DC coupled storage

Specifications:

Voltage Rating: 120/240 Vac
Frequency Rating: 60 Hz
Busbar Rating: 225 A
Short Circuit Current: 22 kA
Operating Temperature: -22 to 122 deg F
Enclosure Rating/IP Rating: NEMA 3R
Dimensions: 39.3 in Width x 14.3 in Height x 6.0 in Depth
Mounting Type: Wall, Flush Or Surface
Connectivity: Ethernet, WiFi (2.5, 5 GHz) Primary, Cellular (4G/LTE, 3G) Secondary
Sub-Feed Lug Rating: 200 A Maximum

What is the SPAN Smart Electrical Panel?

The SPAN Smart Electrical Panel SPN-1-00800 is a state-of-the-art solution for modern homes that prioritizes energy efficiency and convenience. This smart electrical panel offers real-time monitoring and control over your home's electrical system. With its intuitive app, you can easily manage energy consumption, automate circuits, and gain insights into your energy usage patterns. This means you'll not only save money on energy bills but also make informed decisions about your energy consumption, which is crucial in today’s eco-conscious world.

Enhanced Control and Monitoring

One of the standout features of the SPAN Smart Electrical Panel is its ability to provide enhanced control over your electrical system. You can manage appliances and devices remotely through the smartphone app, thus ensuring you can turn off devices when not in use. This not only improves safety but also helps in preventing potential electrical hazards. Moreover, the panel allows you to set schedules for when specific circuits can be on or off, providing convenience and efficiency that traditional panels simply cannot match.

Benefits of Smart Energy Management

By integrating the SPAN Smart Electrical Panel into your home, you can benefit from significant energy savings. Because the panel helps identify which devices consume the most electricity, you can make smarter choices to reduce energy waste. Additionally, this technology facilitates easy upgrades, so you can integrate renewable energy sources, like solar panels, seamlessly. Therefore, with the SPAN Smart Electrical Panel, you're not just upgrading your electrical system; you're investing in a smarter, greener future.

Documents

• Specification Sheet
