Solis 36kW 480V Three-Phase Grid-Tied Inverter | S6-GC36K-US-APST

Solis 36kW 480V Three-Phase Grid-Tied String Inverter

Build your three-phase solar system around the Solis S6-GC36K-US-APST. This grid-tied string inverter delivers 36,000W rated AC output at 480V and uses three independent MPPT trackers to manage separate PV inputs.

Integrated AFCI protection, AC and DC disconnects, and an included APSystems module-level rapid-shutdown transmitter bring key system functions into one inverter. Confirm compatible rapid-shutdown devices and system requirements during installation planning.

Key features

• Three independent maximum power point trackers (MPPTs)
• String current up to 20A
• 98.8% peak efficiency and 98.3% CEC efficiency
• Integrated arc-fault circuit interrupter (AFCI) protection
• Included APSystems module-level rapid-shutdown transmitter
• Integrated AC and DC disconnects with separable AC wiring box
• Type 4X enclosure and intelligent redundant fan cooling

Technical specifications

• Model: S6-GC36K-US-APST
• Series: S6-GC(25–60)K-US
• Rated AC output power: 36kW
• Maximum apparent output power: 36kVA
• AC output voltage: 480 VAC, three-phase
• Maximum input voltage: 1000 VDC
• MPPT trackers: 3

Warranty and documentation

10-year standard warranty, subject to the manufacturer's applicable terms. Confirm extension options with the supplier.

Datasheet: View the Solis S6-GC(25–60)K-US series datasheet (PDF)
