Solis 185kW 3-Phase String Inverter | 185K-EHV-5G-US-PLUS

The Solis 185kW 3-Phase Inverter (SKU: SOLIS-185K-EHV-5G-US-PLUS-10) is a high-performance commercial and industrial string inverter with 12 MPPT inputs and a maximum input voltage of 1500 V. It includes a 10-year standard warranty and is ideal for large-scale commercial and utility solar projects.

Key Features

• 185 kW rated output power
• 12 MPPT channels, 24 input strings
• Max input voltage: 1500 V DC
• Start-up voltage: 500 V DC
• MPPT voltage range: 480–1500 V DC
• Maximum string input current: 15 A
• Supports "Y" type connection on DC side
• Built-in AFCI protection
• Built-in PID recovery for better module performance
• Fuse-free design — safe and maintenance-free
• IP66 enclosure
• CA Rule 21 compliant and UL 1741 SA Certified
• Nighttime PID recovery function

Electrical Specifications

• Rated Output Power: 185 kW / 185 kVA @ 600 VAC
• Max Input Voltage: 1500 V DC
• Number of MPPTs: 12
• Max Input Strings: 24
• Rated Grid Frequency: 60 Hz
• Output Voltage: 600 VAC (3-phase)

Compliance

UL 1741, UL 1741 SA, CA Rule 21, IP66

Warranty

10-year standard warranty (included in SKU: SOLIS-185K-EHV-5G-US-PLUS-10)

Datasheet

Download Solis 185K-EHV-5G-US Datasheet (PDF)
