Rich Solar NOVA 8K PV Hybrid Inverter | All-In-One Solar Inverter | 8000W PV Input | 6000W Output | 48V 120/240V Split Phase

Explore the Features and Benefits of the Rich Solar NOVA 8K Hybrid Inverter

With the Renogy 320W Solar Panel Pack, you can transform your structure into an energy-producing hub with just a few easy steps. This incredible solar panel set features 8 power-packed, high-efficiency solar modules that are small and light, while delivering impressive outputs of up to 320W. With the new PERC technology, featuring smoother module output performance, it allows you to optimize your roof space and install fewer modules per installation. Thanks to the cell's impressive 21% efficiency rate, you will benefit from significantly reduced electricity bills and higher electricity production. Installing this solar panel is a hassle-free process that is able to withstand extreme weather conditions, making it a reliable and durable option. With the RENOGY 320W Solar Panel Pack, you'll be able to produce clean and affordable energy without a hitch.

Features

• IP65 waterproof and dustproof makes the inverter available for various working conditions
• Configurable color with the built-in RGB LED bar
• Built-in Wi-Fi for mobile monitoring (APP is required)
• Built-in alternative port for generator and emergent load
• Optional external CT sensor to guarantee 100% self-consumption
• Programmable supply priority for PV, Battery or Grid
• Built-in communication port for BMS (RS485)
• User-adjustable charging current and voltage
• Parallel operation up to 6 units


Specifications

• Type: All-In-One Solar, Split Phase
• Dimensions:
  • Width: 515 mm
  • Height: 700 mm
  • Depth: 215.5 mm
• Phase:
  • 120/240 V Split Phase
  • 120/208 V Two-Third Phase
• Maximum PV Input Power: 7500 W
• Maximum DC Voltage: 600 VDC
• Start-Up Voltage / Initial Feeding Voltage: 125 VDC / 160 VDC
• MPP Voltage Range: 120-550 VDC
• Number of MPPT Trackers / Maximum Input Current: 2 / 15 A
• Rated Output Power: 6000 VA / 6000 W
• Nominal Output Voltage:
  • 120 VAC (P-N)
  • 208 VAC (P-P)
  • 240 VAC (P-P)
• Output Voltage Range: 105.5-132 VAC Per Phase
• Nominal Output Current: 25 A Per Phase
• Battery DC Voltage Range: 40 - 62 VDC
• Maximum Solar Charge Current: 120 A
• Maximum AC Charging Current: 120 A
• Maximum Charging Current: 120 A
• Maximum Charging Power: 6000 W
• Power Factor: 0.9 Lag to 0.9 Lead - Grid Output (AC)
• Maximum Conversion Efficiency (DC/AC): 96% - Grid-Tie Operation
• AC Input Start-Up Voltage / Auto Restart Voltage: 85 VAC Per Phase / 90 VAC Per Phase - Off-Grid Operation
• Acceptable AC Input Voltage Range: 85-140 VAC (P-N) (Per Phase) - Off-Grid Operation
• AC Input Frequency Rating: 50/60 Hz (Auto Sensing) - Off-Grid Operation
• Maximum AC Input Current: 40 A Per Phase
• Efficiency (DC to AC): 91% - Battery Mode Output (AC)
• Output Waveform: Pure Sine Wave - Battery Mode Output (AC)
• Parallel Function: Yes, 6 Units
• Communication Ports: RS232, RS485, WI-FI, USB
• Operating Temperature: -25 to 60°C (>45°C Derating)
• Enclosure Rating: IP65
• Standards:
  • UL 1741SAm
  • CSA 22.2.1071
  • IEEE 1547:2020
  • FCC CRF47 PART15 B
  • TUV
  • ETL Listed
  • PV Cycle
  • MCS
  • IEC
• Warranty: 2 Years
• Weight: 41 kg


Documents

• Specification Sheet
• Owners/User Manual

Powerful Performance with High PV Input Capacity

The Rich Solar NOVA 8K hybrid inverter is designed to deliver outstanding solar energy conversion with an impressive 8000W PV input capacity. This capability allows it to efficiently capture and convert solar power from large photovoltaic arrays, maximizing energy harvest. The inverter's 6000W output ensures reliable electricity supply for residential or light commercial use. This robust input-output combination makes the Rich Solar NOVA 8K hybrid inverter an ideal choice for users seeking a resilient and efficient solar energy system that balances power generation and consumption seamlessly.

Advanced Hybrid Technology for Energy Optimization

Equipped with state-of-the-art hybrid inverter technology, the Rich Solar NOVA 8K hybrid inverter intelligently manages energy from solar panels, battery storage, and the grid. This all-in-one solar inverter optimizes energy usage by prioritizing solar power and battery reserves before drawing from the grid, reducing electricity costs and enhancing energy independence. Its 48V battery compatibility supports efficient energy storage solutions. Additionally, the 120/240V split-phase output accommodates a wide range of household electrical configurations, delivering flexible and consistent power management.

Durable Design and User-Friendly Operation

The Rich Solar NOVA 8K hybrid inverter is built with durability and ease of use in mind, making it suitable for varied environmental conditions. Its robust enclosure protects internal components, ensuring long-lasting reliability. The inverter includes intuitive controls and a clear display, enabling users to monitor system performance and status with ease. Installation is straightforward, supported by comprehensive guidance. This inverter represents an excellent investment for users looking for a hassle-free, powerful solar inverter that supports their clean energy goals.
