REC TwinPeak 4 REC365TP4 Black 365W Solar Panel

The REC 365 watt monocrystalline solar panel delivers high power output and performance for residential projects. The REC Twinpeak 4 Black module features 120 half-cut monocrystalline silicon cells on a black backsheet with a black anodized aluminum frame for lightweight and exceptional durability. Operating at 20.0% efficiency, the REC365TP4 is the best in terms of high energy yields with sleek black-on-black aesthetics. Built to withstand up to a 7000 Pa heavy snow load and a wind load up to 4000 Pa, REC solar modules are highly reliable and durable.

Specifications

• Series: TwinPeak 4 Black
• Dimensions: 69.1 in x 40.94 in x 1.2 in
• Wire Size: 12 AWG
• Material: Anodized Aluminum Frame, Highly Resistant Polymer Backsheet
• Color: Black Frame
• Power Voltage: 34.3 V
• Power Current: 10.65 A
• Power Rating: 365 W
• Short Circuit Current: 11.32 A
• Cell Type: Half-Cut Mono C-Si N-Type
• Number of Cells: 120
• Operating Temperature: -40 to 185 deg F
• Efficiency: 0.2%
• Fuse Rating: 25 A

Documents

• Brochure
