R9C3100U - UL98 C-Frame 3-Pole, 100AMP NF Rotary Disconnect

Reliable 100 Amp Rotary Disconnect Switch for Industrial Safety

UL98 C-Frame 3-Pole, 100AMP NF Rotary Disconnect
Eaton Rotary Disconnect Switch, 100 A, Non-Fusible, Three-Pole, Switch Body, R9 Series, 600 V, C Frame

Eaton's full-range of rotary disconnects offers a compact, economical, and high-quality choice for switching and isolation spanning a range from 16A - 1200A. The R5 Series of switches are UL 508 listed devices, suitable for use as motor disconnects. The R9 offering consists of UL 98 listed fusible and non-fusible products that may be used for service entrance, or anywhere a local means of disconnect is needed or required.

Key Features:

• Amperage rating: 100A
• Poles: 3-pole
• Voltage rating: 600V


Documents:

Specifications and datasheets
Eaton Specification Sheet - R9C3100U

Durable Design and Construction

The R9C3100U 100 amp rotary disconnect switch features a robust UL98 C-frame construction ensuring high durability and long service life. This 3-pole switch is engineered to withstand demanding industrial environments, providing secure and reliable electrical disconnection. Its rugged design protects internal contacts from environmental stresses, making it ideal for applications requiring consistent safety standards and maintenance accessibility.

Enhanced Safety and Compliance

This 100 amp rotary disconnect switch complies fully with UL98 safety standards, guaranteeing safe operation and user protection during electrical disconnection. The visible blade design allows technicians to clearly verify the disconnect position, reducing risks during maintenance. The switch’s natural finish and secure rotary mechanism help prevent accidental engagement or disengagement, further enhancing operational safety in industrial setups.

Versatile Application and Easy Installation

The R9C3100U switch is designed for varied industrial applications, including motor control centers, machinery, and HVAC systems. Its compact 3-pole configuration simplifies integration within electrical panels, offering seamless installation and reliable performance. The switch’s rotary handle enables intuitive manual operation, making this 100 amp rotary disconnect switch a versatile and practical solution for power isolation needs.
