Qcells 410W Q.Peak Duo BLK ML-G10.C+ Solar Panel Domestic Content
Qcells 410W Q.PEAK DUO BLK ML-G10.C+ Solar Panel – Domestic Content Option
High-efficiency. Sleek all-black design. Built with U.S. manufactured components.
The Qcells 410W Q.PEAK DUO BLK ML-G10.C+ delivers up to 21.1% module efficiency with Q.ANTUM DUO Z technology and zero-gap cell layout. Designed for residential rooftop systems, this all-black 132-half-cell module combines premium aesthetics with proven long-term reliability — plus Domestic Content that may contribute toward qualifying projects for the 10% domestic content bonus under the Inflation Reduction Act.
MPN: Q.PEAK DUO BLK ML-G10.C+ 410W DCA
Key Benefits
- Domestic Content Option Available – Contains U.S. manufactured components which may contribute to qualification for the 10% domestic content bonus under the Inflation Reduction Act (consult a qualified tax professional).
- High Efficiency Performance – Up to 21.1% module efficiency with Q.ANTUM DUO Z zero-gap cell layout technology.
- Reliable Long-Term Output – Backed by a 25-year product warranty and 25-year linear performance warranty.
- Extreme Weather Rated – 5400 Pa snow load (113 lbs/ft²) | 4000 Pa wind load (84 lbs/ft²).
- Low Degradation Rate – ≥98% nominal power in year 1 | Max. 0.5% annual degradation | ≥86% power output at year 25.
- Advanced Cell Protection – Anti-LeTID, Anti-PID, and Hot-Spot Protect technologies.
Best Uses
- Residential rooftop arrays
- IRA-driven projects targeting domestic content qualification
- Homeowner systems prioritizing aesthetics (all-black frame & backsheet)
- High-snow or high-wind regions
Electrical Specifications (STC)
| Specification | Value |
|---|---|
| Rated Power (Pmax) | 410 W |
| Module Efficiency | ≥ 20.9% |
| Open Circuit Voltage (Voc) | 45.37 V |
| Short Circuit Current (Isc) | 11.20 A |
| Voltage at MPP (Vmp) | 37.64 V |
| Current at MPP (Imp) | 10.89 A |
| Power Tolerance | +5W / –0W |
Performance at NMOT
| Specification | Value |
|---|---|
| Power at MPP | 307.6 W |
| Open Circuit Voltage | 42.79 V |
| Short Circuit Current | 9.03 A |
| Voltage at MPP | 35.68 V |
| Current at MPP | 8.62 A |
Mechanical Specifications
| Specification | Value |
|---|---|
| Dimensions | 74.0 in × 41.1 in × 1.26 in (1879 mm × 1045 mm × 32 mm) |
| Weight | 48.5 lbs (22.0 kg) |
| Cell Type | 6 × 22 Monocrystalline Q.ANTUM Half Cells (132 total) |
| Front Glass | 3.2 mm tempered anti-reflective glass |
| Frame | Black anodized aluminum |
| Backsheet | Composite film |
| Junction Box | IP67 rated with bypass diodes |
| Cable Length | ≥ 72.04 in (1830 mm) |
| Connector | Stäubli MC4 (IP68) |
System Design Specifications
| Specification | Value |
|---|---|
| Maximum System Voltage | 1000V (IEC / UL) |
| Max Series Fuse Rating | 20 A |
| Fire Rating | UL 61730 Type 2 |
| Operating Temperature | -40°F to +185°F |
| Max Design Load (Push/Pull) | 75 / 55 lbs/ft² |
| Max Test Load (Push/Pull) | 113 / 84 lbs/ft² |
Temperature Coefficients
| Specification | Value |
|---|---|
| Temp Coefficient of Pmax | -0.34 %/°C |
| Temp Coefficient of Voc | -0.27 %/°C |
| Temp Coefficient of Isc | +0.04 %/°C |
| NMOT | 109°F ± 5.4°F (43°C ± 3°C) |
Certifications
- UL 61730-1 & UL 61730-2
- IEC 61215:2016
- IEC 61730:2016
- TÜV Rheinland certified
- CE compliant
Warranty
- 25-Year Product Warranty
- 25-Year Linear Performance Warranty
- ≥98% of nominal power in year 1
- Max. 0.5% annual degradation thereafter
- ≥86% power output at year 25
Datasheet
Download Official Qcells Q.PEAK DUO BLK ML-G10.C+ Datasheet (PDF)
