Pylontech Force H1 Stack-2 Batteries, 7.10 kWh (SKU Part Number FH48074-FH1, FC0500-40S-V2-FH1)

The Force H1 is the high voltage battery storage system provided by Pylontech. The newly designed system provides easy connector to save valuable time for installers. The stacking system provides flexible configurations from 96V to 384V voltage and 7.1 kWh to 149.1 kWh capacity.

Features

• Safety and Reliability - ensured by own designed and manufactured cell, modules and BMS
• Optimal electricity cost - long cycle life and superior performance
• Strong scalability - maximum capacity of 215.04 kWh with 6 groups in parallel
• Flexible mounting - plug and play, no additional wiring connection
• Compatibility - Top inverter brands
• Flexible module design
• 95% dod
• 10+ years technical proven
• Expandable from 7-149.1kwh
• Suitable for indoor/outdoor installation


Specifications

• Battery System Capacity: 7.10 kWh
• Voltage Range: 43.5-54 V
• Depth of Discharge: 95%
• Charge/Discharge Current: 30 A (Recommended), 75 A (Maximum), 105 A (Peak at 15 sec)
• Multi-Group: Maximum 6 Systems in Parallel
• Communication Port: RS485, CAN
• Enclosure Rating: IP55
• Working Temperature: 0-50°C
• Shelf Temperature: -20-60°C
• Humidity: 5-95% (W/O Condensing)
• Altitude: <6562 ft
• Design Life: 15+ Years
• Cycle Life: >8000
• Standards: VDE2510-50, IEC 62619, IEC 62477, CE Certified, UN38.3


Documents

• Specification Sheet
• Instruction/Installation Manual
