PDG23M0100TFFL - PDG2 3P 100A 65KA 480V Breaker

The PDG2 3P 100A 65KA 480V Breaker is a high-performance circuit protection device designed for commercial and industrial electrical systems. It provides reliable overcurrent protection for critical applications, ensuring the safety and stability of your power distribution network. Built to handle demanding environments, this breaker is rated for 65kA interrupting capacity at 480V, delivering robust protection against short circuits and overloads. It integrates seamlessly into Eaton panelboards and switchboards, offering ease of installation and dependable operation.

Key Features:

• Device Type: Molded Case Circuit Breaker (MCCB)
• Poles: 3
• Current Rating: 100 Amps
• Interrupting Rating: 65kA at 480V
• Voltage Rating: 480 Volts AC
• Compatibility: Suitable for Eaton panelboards and switchboards
• Construction: Durable design for long-lasting performance
• Installation: Simple and secure mounting

This breaker is a critical component to enhance the protection and reliability of your electrical distribution system, helping to safeguard equipment and maintain operational continuity.

Documents:

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Installation instructions
Power Defense Frame 1 IEC and Frame 2 Rotary Mechanism with NFPA Handle Attachment Instructions (IL012260EN).pdf

Specifications and datasheets
Eaton Specification Sheet - PDG23M0100TFFL
