PDG23G0100TFFL - Eaton Power Defense Molded Case Circuit Breaker

The Eaton Power Defense Molded Case Circuit Breaker offers top-tier protection with a 100A current rating and a 35KA short-circuit interrupting capacity. Its three-pole design and frame 2 construction provide ease of installation, while the breaker is globally rated to meet international standards. The T-M (FXD-FXD) Tu configuration and standard terminals are designed specifically for load-only applications, making this breaker ideal for use in both commercial and industrial environments where safety and reliability are paramount.

Key Features:

• 100A current rating for robust protection
• 35KA short-circuit interrupting rating for enhanced safety
• Globally rated for international applications
• Three-pole design for versatile functionality
• Frame 2 for straightforward installation
• Standard terminals load only for flexible usage

This Eaton circuit breaker ensures effective and safe operation in electrical systems across various industrial and commercial applications.

Documents:

3D CAD drawing package
Eaton Power Defense PDG23G0100TFFL 3D drawing

Application notes
Consulting application guide - molded case circuit breakers

Brochures
Power Defense molded case circuit breaker selection poster

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Certification reports
EU Declaration of Conformity - Power Defense molded case circuit breakers

Installation instructions
Power Defense Frame 2/3/4/5/6 voltage neutral sensor module wiring instructions – IL012316EN
