PDG23G0060TFFL - Eaton Power Defense Molded Case Circuit Breaker

The Eaton Power Defense Molded Case Circuit Breaker is engineered to deliver exceptional protection for your electrical system. With a 60A current rating and a 35KA short-circuit interrupting capacity, it ensures maximum safety and reliability in demanding applications. The three-pole, frame 2 design allows for easy installation, while the globally rated features make it compatible with international standards. Its T-M (FXD-FXD) Tu configuration and standard terminals are designed for load-only applications, making it a versatile choice for commercial and industrial settings.

Key Features:

• 60A current rating for reliable protection
• 35KA short-circuit interrupting rating for high-capacity safety
• Globally rated for international compatibility
• Three-pole design for versatile use
• Frame 2 for quick and easy installation
• Standard terminals load only for flexible application

This Eaton circuit breaker is a robust solution for electrical safety in various commercial and industrial environments.
