Outback 30 Amp 120/240 VAC double pole panel mount breaker for AC Coupling in the GSLC. (SKU Part Number PNL-30D-AC-120/240)

30 A 120/240VAC double pole panel mount breaker with 1/4" stud terminals. Used to connect AC Coupled grid-tie inverter inside of GS load center.

Features

• Front panel mount, single and double pole with stud terminals on the back
• Conductor ring terminals required
• Used for DC sources, inverters and load circuits
• Panel mounted hydraulic-magnetic type breakers
• Rated for 100% continuous duty cycle
• Not affected by high ambient temperatures
• Non-polarized for use in any wiring orientation
• Contact OutBack for additional information


Specifications

• Type: Hydraulic-Magnetic
• Voltage Rating: 120/240 VAC
• Current Rating: 30 A
• Number of Poles: 2
• Mounting Type: Panel
• Terminals: 1/4 in Stud
• Branch Circuit: 10 kAIC
• Suitable For Use With: Input, Output or Load Circuits
• Standards: UL Listed
• Dimensions: 1.5 in Width


Documents

• Specification Sheet
• Cut Sheet
