IronRidge PV Grounding Lug

IronRidge PV Grounding Lug: Essential Grounding Solution for Solar Systems

At the core of the BX system is the Chassis, a ballasted mount made of BASF Ultramid. Ultramid polyamides (nylon) are exceptional for their high mechanical strength, rigidity and thermal stability. Moreover, Ultramid polyamides afford good impact resistance even at low temperatures, advantageous sliding friction properties and problem-free processing. Chassis come in 5 and 10 deg options.

Features

• Low profile
• Mounts to module frame
• One per continuous array


Specifications

• Material: 300 Series Stainless Steel
• Finish: Silver
• Standards: CE, ETL, IEC, UL Listed
• Includes: Grounding Lug, 1/4-28 x 0.750 in Hex Bolt, 8-32 x 0.5 in Hex Flange Bolt, 8-32 Hex Nut Flange, Washer
• Warranty: 25 Years
• Weight: 5 lb


Documents

• Specification Sheet
• Instruction/Installation Manual
• Warranty Information

Product Overview and Key Features

The IronRidge PV Grounding Lug is a crucial component designed specifically for photovoltaic (PV) solar systems. It ensures a secure and reliable electrical connection between the solar panel frame and the system grounding conductor. Manufactured with high-quality materials, this grounding lug offers excellent corrosion resistance and strong conductivity, making it ideal for various outdoor environments. The IronRidge PV Grounding Lug makes installation straightforward, providing peace of mind by complying with electrical safety standards and enhancing the overall durability of solar power setups.

Benefits of Using IronRidge PV Grounding Lug

Using the IronRidge PV Grounding Lug enhances the safety of your solar installation by effectively preventing electrical faults and protecting against lightning surges. Its robust design ensures consistent performance, minimizing maintenance needs over the lifespan of the PV system. The lug offers quick attachment to IronRidge mounting rails, cutting down installation time and complexity. Additionally, it contributes to the longevity of your solar array by safeguarding the system’s metal parts from corrosion and electrical damage, ensuring sustained operation and reliability.

Installation and Compatibility

The IronRidge PV Grounding Lug is engineered for compatibility with IronRidge solar mounting rails and many other common PV system components. Installation requires minimal tools, with a simple set screw mechanism for secure attachment. This grounding lug fits standard grounding wires and adapts easily to various system sizes, simplifying integration into new or existing solar arrays. Clear installation instructions help professionals and DIY users maintain compliance with local electrical codes, making the IronRidge PV Grounding Lug a trusted choice for dependable and professional grounding solutions.
