IronRidge Ground Mount Bonded Rail Connector | 3"

IronRidge's Bonded rail connectors attaches and bonds horizontal 3 in Schedule 40 cross pipes to XR1000 Rails. Each rail requires two connectors to create a secure and bonded attachment. The Rail Connector is manufactured using extruded 6000 series aluminum and is also available in 2 in size.

Features

• In accordance with NEC 2023, requires a tool to open
• Proven MULTILAM technology with high long-term stability, which ensures consistently low performance loss throughout the entire service life of the plug connector
• Tried and tested plug connectors, over 25 years of experience in the field
• Available for assembly with cross-sections up to 10 sq-mm
• Also available as ready made leads according to customer's specification
• To be used with suitable mated connectors from the MC4 product family and suitable lead
• Specifications

• Material: Aluminum
• Suitable For Use With: Attaches & Bonds Horizontal Cross 3 in Pipes to XR1000 Rails
• Finish: Mill


Documents

• Specification Sheet
