HMCPE070M2C - Eaton Molded Case Circuit Breaker Accessory Motor Protection

The Eaton Motor Circuit Protector is a high-performance accessory designed to deliver adjustable protection for motors in critical industrial applications. This 70A, three-pole unit accommodates adjustable current settings between 210A and 700A, making it ideal for a broad range of motor loads. Compatible with Frame EG and operating at up to 480V and 600Y/347V, it provides robust protection against overloads and short circuits. Constructed with non-aluminum materials, it enhances durability and reliability in challenging environments. As part of Eaton's Series G, it integrates seamlessly with related systems for streamlined deployment.

Key Features:

• Adjustable motor protection for 210-700A applications
• Rated at 70A with a three-pole configuration
• Supports 480V and 600Y/347V system voltages
• Built for use with Frame EG and Eaton Series G systems
• Non-aluminum build ensures long-term performance

A dependable solution for safeguarding motors in high-demand electrical systems.
