HMCPE030H1C - Eaton Molded Case Circuit Breaker Accessory Motor Protection

The Eaton Motor Circuit Protector is a robust accessory designed for advanced motor protection in industrial and commercial electrical systems. This 30A, three-pole unit supports adjustable motor protection settings for circuits ranging from 90 to 300A, making it highly versatile. Designed for use with Frame J-K and operating at up to 480V (and 600Y/347V systems), it helps safeguard motors from short circuits and overloads. Constructed with non-aluminum materials, it offers enhanced durability in demanding environments. The Series G configuration ensures compatibility and performance across Eaton systems.

Key Features:

• Adjustable motor protection for circuits rated 90-300A
• Three-pole design with 30A current rating
• Supports 480V and 600Y/347V system voltages
• Compatible with Eaton Frame J-K and Series G breakers
• Non-aluminum construction for enhanced strength and longevity

Ideal for flexible and reliable motor circuit protection across a wide range of industrial applications.

Documents:

Application notes
Application of Tap Rules to Molded Case Breaker Terminals

Brochures
Current limiting molded case circuit breaker module product aid

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Multimedia
Flex shaft handle installation tutorial

Specifications and datasheets
Eaton Specification Sheet - HMCPE030H1C
