HMCP100R3C - Eaton Molded Case Circuit Breaker Accessory Motor Protection

The Eaton Molded Case Circuit Breaker Accessory Motor Protection is engineered to deliver robust and efficient protection for motor circuits in industrial and commercial settings. With a 100 A current rating and three-pole configuration, it supports a wide trip range of 300–1000 A. Compatible with Series C J-K frame breakers, this motor circuit protector is built with non-aluminum components for enhanced durability and performance in demanding environments.

Key Features:

• 100 A current rating for reliable motor circuit protection
• Three-pole design for balanced load distribution
• Compatible with J-K frame, 300–1000 A, Series C breakers
• Non-aluminum construction for long-lasting durability

This Eaton Molded Case Circuit Breaker Accessory Motor Protection ensures dependable performance and safety across a wide range of motor control applications.

Documents:

Application notes

Application of Multi-Wire Terminals for Molded Case Circuit Breakers
Brochures

Motor protection circuit breakers product aid
Catalogs

Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Multimedia

Flex shaft handle installation tutorial
Specifications and datasheets

Series C J-Frame molded case circuit breakers time current curves
