HMCP100R3 - Motor Cicuit Protector

The Motor Circuit Protector, 100 A is designed to deliver reliable and adjustable protection for motor circuits in industrial environments. With a NEMA 3 starter size and a magnetic trip tripping mechanism, it provides rapid response to overcurrent conditions. This unit features a wide trip setting range of 300 to 1000 A, along with line and load lug terminals for secure connections. Built on a durable F-frame, it supports both 600 V AC and 250 V DC operations, with a compact form factor for flexible installation.

Key Features:

• 100 A current rating with magnetic trip tripping mechanism
• Adjustable trip setting range from 300 to 1000 A
• Line and load lug terminals for secure and reliable wiring
• Supports 600 V AC and 250 V DC applications
• Dimensions: 6 in overall height, 3.38 in overall length
• Durable F-frame construction for long-term performance

This Motor Circuit Protector, 100 A offers dependable protection and operational flexibility, making it ideal for a wide range of motor-driven systems.

Documents:

Application notes

Application of Tap Rules to Molded Case Breaker Terminals
Brochures

Power metering and monitoring with Modbus RTU product aid
Catalogs

Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Multimedia

Flex shaft handle installation tutorial
Specifications and datasheets

Eaton Specification Sheet - HMCP100R3
