HMCP050K2C - Motor Cicuit Protector

The Motor Circuit Protector, 50 A is engineered for efficient and reliable protection of motor circuits across a variety of industrial applications. With a NEMA 2 starter size and a magnetic trip mechanism, this unit provides fast response to overcurrent conditions. Designed with a trip setting range of 50 to 500 A and equipped with both line and load lug terminals, it supports operation at 600 V AC and 250 V DC. The robust F-frame construction ensures long-lasting performance.

Key Features:

• 50 A current rating with magnetic trip tripping mechanism
• Trip setting adjustable from 50 to 500 A for flexible protection
• Line and load lug terminals for secure connections
• Supports 600 V AC and 250 V DC applications
• Built with durable F-frame construction

This Motor Circuit Protector, 50 A delivers dependable and adjustable protection, making it ideal for safeguarding motors in demanding environments.

Documents:

Application notes

UL listed 100%-rated molded case circuit breakers
Brochures

Current limiting Series C molded case circuit breakers product aid
Catalogs

Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2
Multimedia

Flex shaft handle installation tutorial
Specifications and datasheets

Eaton Specification Sheet - HMCP050K2C
