GHB3090 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C GHB Molded Case Circuit Breaker is designed to deliver high-performance protection in demanding commercial and industrial applications. This three-pole breaker features a G-frame construction and utilizes fixed thermal and fixed magnetic trip types to provide dependable defense against overloads and short circuits. With a 90A current rating, it supports both 480Y/277 Vac and 125/250 VDC, offering flexibility for a range of power systems. Operating at 50/60 Hz, it ensures safe and stable circuit control in multi-phase environments.

Key Features:

• Fixed thermal and magnetic trip types for consistent and reliable protection
• Three-pole configuration for balanced load distribution
• 90A current rating compatible with 480Y/277 Vac and 125/250 VDC systems
• Operates on standard 50/60 Hz frequencies
• Ideal for industrial and commercial power applications

This Eaton Series C breaker provides robust protection and performance for critical electrical circuits.
