GHB3080 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C GHB Molded Case Circuit Breaker is built for dependable performance in commercial and industrial power distribution systems. Featuring a G-frame design with fixed thermal and fixed magnetic trip types, this three-pole breaker provides reliable protection against overloads and short circuits. With an 80A current rating, it supports both AC (480Y/277 Vac) and DC (125/250 VDC) operations, making it suitable for a wide range of applications. Operating at 50/60 Hz, this breaker ensures safe, consistent, and efficient circuit management.

Key Features:

• Fixed thermal and magnetic trip types for consistent circuit protection
• Three-pole configuration for enhanced load handling
• 80A current rating compatible with 480Y/277 Vac and 125/250 VDC
• Operates on 50/60 Hz electrical systems
• Suitable for demanding industrial and commercial applications

This Eaton Series C breaker provides reliable and efficient protection for high-performance electrical systems.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Motor protection circuit breakers product aid

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Multimedia
Circuit breakers explained
