GHB3045 - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C GHB Molded Case Circuit Breaker is designed to deliver consistent and reliable protection for electrical systems in demanding industrial and commercial environments. This three-pole breaker features a G-frame design with fixed thermal and fixed magnetic trip types, providing effective defense against overloads and short circuits. With a 45A current rating, it supports voltage ratings of 480Y/277 Vac and 125/250 VDC, offering flexibility for both AC and DC applications. Suitable for 50/60 Hz systems, this breaker ensures safe and efficient power distribution.

Key Features:

• Fixed thermal and magnetic trip types for reliable protection
• Three-pole configuration for comprehensive circuit coverage
• 45A rating compatible with 480Y/277 Vac and 125/250 VDC
• Designed for use in 50/60 Hz electrical systems
• Suitable for a wide range of commercial and industrial applications

This Eaton Series C breaker ensures dependable performance and protection across multi-phase electrical systems.

Documents:

Application notes

Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Plug-in adapters for molded case circuit breakers product aid

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Multimedia
Circuit Breakers Explained
