Fortress Power FP-Nano-30K-L eSpire Nano 30kW Three-Phase Hybrid Inverter
-
Estimated Delivery:Oct 02 - Oct 06
-
Free Shipping & Returns: On all orders under $50
Fortress Power FP-Nano-30K-L eSpire Nano 30kW Three-Phase Hybrid Inverter
Fortress Power FP-Nano-30K-L eSpire Nano 30kW Three-Phase Hybrid Inverter
The Fortress Power FP-Nano-30K-L eSpire Nano 30kW Three-Phase Hybrid Inverter is a 30 kW three-phase hybrid inverter for 208Y/120V commercial and industrial systems. It manages DC-coupled solar input, battery charging and discharging, and backup output from a single outdoor-rated unit, and pairs with eSpire Nano high-voltage LFP battery cabinets to support peak shaving, time-of-use load shifting, self-consumption, microgrid, and off-grid operation.
Three independent MPPTs accept up to six PV strings and 60 kW of usable PV input across a 150–850 V operating window. The inverter also supports high-leg delta (240V 3P4W) service in grid-tied mode.
Key Features
- 30 kW rated AC output, 26 kW backup at 208 V — transfer to backup in under 10 ms
- Three MPPTs and 60 kW usable PV — each MPPT operates independently for arrays on different roof planes
- 33 kW battery charge and discharge power — enough throughput to move a full 40 kWh or 60 kWh cabinet through a demand-charge window
- Smart ports for a generator, AC-coupled PV, or one load circuit — generator 2-wire start supported
- Export power control included — supplied meter and CT set enforce kW export limit or disable export entirely
- Up to six inverters in parallel — all units must be the same model and share the same AC panels
- Metering hardware in the box — Eastron SDM630MCT meter, three 600 A Rogowski coils, wall-mount bracket, and communication dongle included
Applications
Built for commercial and industrial sites on 208Y/120V three-phase service: grocery and convenience stores, schools, banks, clinics, manufacturing plants, and charging or service areas. Typical uses include demand-charge management through peak shaving, time-of-use arbitrage, backup for a critical-load panel, microgrid operation alongside a generator, and full off-grid systems.
Technical Specifications
| Specification | Value |
|---|---|
| AC Configuration | 208Y/120V three-phase (208 / 220 / 240 Vac 3P4W); high-leg delta 240V 3P4W supported in grid-tied mode only |
| Rated AC Output Power | 30 kW |
| Rated AC Output Current | 72.2 A |
| Max. Apparent AC Output Power | 26 kVA |
| Rated Backup Power Output | 26 kW at 208 V (27.5 kW at 220 V, 30 kW at 240 V) |
| Max. Backup Current Output | 86.6 A (5 min) / 101.8 A (1 min) / 108.3 A (10 s) / 115.5 A (2 s) |
| Backup Switch Time | Under 10 ms |
| Max. AC Passthrough Current | 144.4 A |
| Max. Battery Charge / Discharge Power | 33 kW |
| Rated Frequency / Input Range | 60 Hz / 55–65 Hz |
| Grid Power Factor | Greater than 0.99 (0.8 leading to 0.8 lagging) |
| THDi / THDv | 3% or less / under 2% at linear load |
| Max. Usable PV Input Power | 60 kW |
| MPPTs / Max. PV Strings | 3 / 6 |
| MPPT Voltage Range | 150–850 V (full load 500–850 V; rated 600 V; start-up 180 V) |
| Max. PV Input Voltage | 1000 V |
| Max. PV Current per MPPT | 42 A continuous (21 A per input); 65 A short circuit |
| Max. Input Power per MPPT | 25 kW |
| Inverter Efficiency | 97.80% |
| Max. Inverters in Parallel | 6 |
| Operating Altitude | Up to 8,202 ft (2,500 m) without derating |
| Weight | Approximately 196 lb |
| Communication | CAN, RS485 (115200), Ethernet; Wi-Fi through included communication dongle |
| Battery Compatibility | Fortress Power eSpire Nano high-voltage batteries only |
| Certifications | UL 1741 SB, UL 3141, CA Rule 21, HECO Rule 14H |
Warranty
10-Year Warranty — 70% capacity retention with 8,000 cycles. Backed by North America-based technical support from project design through commissioning.
System Compatibility
The eSpire Nano hybrid inverter operates with Fortress Power eSpire Nano high-voltage batteries only. Compatible batteries include:
- FP-Nano-S8-O — 40 kWh outdoor high-voltage battery
- FP-Nano-S12-O — 60 kWh outdoor high-voltage battery
- FP-Nano-S8-I — 40 kWh indoor high-voltage battery
- FP-Nano-S12-I — 60 kWh indoor high-voltage battery
Product Documents
- Fortress Power eSpire Nano Data Sheet (English)
- Fortress Power eSpire Nano Data Sheet (Spanish)
- eSpire Nano Inverter Installation Manual
- eSpire Nano Battery Installation Manual
- eSpire Nano UL1741 CRDMM Certification
- eSpire Nano UL1741 Certification
- eSpire Nano UL1973 Outdoor Certification
- eSpire Nano UL3141 Certification
- eSpire Nano UL9540 Outdoor Certification
- eSpire Nano UL9540A Outdoor Certification
