EHD3020L - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker is designed for use in industrial and commercial applications where high performance and reliability are required. The F-frame circuit breaker features fixed thermal and fixed magnetic trip types, ensuring optimal protection for your electrical systems. With a 20A rating and impressive short-circuit withstand ratings of 18kAIC at 240 Vac and 14kAIC at 480 Vac, this breaker provides both safety and durability. Its three-pole configuration offers versatile protection for a wide range of equipment, and the line and load terminals make installation straightforward. Ideal for use in systems requiring dependable and high-capacity circuit protection.

Key Features:

• Fixed thermal and magnetic trip types for consistent protection
• Three-pole configuration suitable for various applications
• 20A rating with high short-circuit withstand ratings (18kAIC at 240 Vac, 14kAIC at 480 Vac)
• Designed for 50/60 Hz applications
• Simple installation with line and load terminals

This Eaton Series C breaker ensures superior safety and performance in your electrical systems.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Current limiting Series C molded case circuit breakers product aid
