EHD3015L - Eaton Series C Complete Molded Case Circuit Breaker

The Eaton Series C Complete Molded Case Circuit Breaker delivers compact and dependable circuit protection for demanding commercial and industrial environments. With a 15A current rating and a three-pole configuration, this breaker features a fixed thermal and fixed magnetic trip unit for reliable response to overloads and short circuits. Housed in an F-frame, it supports both line and load terminals and operates at 50/60 Hz. It offers an interrupting capacity of 18 Kaic at 240V AC and 14 Kaic at 480V AC, making it a solid choice for medium-duty protection.

Key Features:

• 15A current rating for dependable circuit protection
• Interrupting capacity: 18 Kaic at 240V, 14 Kaic at 480V
• Fixed thermal and magnetic trip unit for consistent performance
• Three-pole design for balanced power distribution
• Supports line and load terminals, 50/60 Hz operation

This molded case circuit breaker provides efficient and safe operation across a range of electrical systems.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit

Brochures
Multi-wire lugs product aid
