EGHMVD24BX0 - Eaton Molded Case Circuit Breaker Accessory Handle Mechanism

Eaton S01 Handle Mechanism is a dependable accessory designed for use with EG-frame molded case circuit breakers from Eaton’s Series G. Featuring a 24-inch shaft and flange-mounted configuration, it allows for safe remote operation in electrical panels. The durable blue handle enhances visibility and control, while the NEMA 4/4X rating ensures protection against harsh environmental conditions such as dust, moisture, and corrosion.

Key Features:

• Handle Mechanism Type: S01
• Compatible Frame: EG (Series G)
• Shaft Length: 24 inches
• Mounting Type: Flange-mounted
• Handle Color: Blue
• Enclosure Rating: NEMA 4/4X

This handle mechanism is ideal for demanding industrial or commercial setups requiring rugged and reliable circuit breaker operation.

Documents:

Application notes
Application of Tap Rules to Molded Case Breaker Terminals
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Molded case circuit breakers providing higher levels of selective coordination product aid

Specifications and datasheets
Eaton Specification Sheet - EGHMVD24BX0
