EGH3030FFG - Eaton Series G Molded Case Circuit Breaker

The Eaton Series G Molded Case Circuit Breaker provides robust protection for industrial and commercial electrical systems. With a 30A current rating and a three-pole design, it features a fixed thermal and fixed magnetic trip unit, ensuring dependable overload and short-circuit protection. Designed for use with systems up to 600Y/347V AC, it offers outstanding interrupting capacities of 100 Kaic at 240V AC, 65 Kaic at 480V AC, and 35 Kaic at 600Y/347V AC. Supporting both line and load terminals and operating at 50/60 Hz, this breaker delivers reliable performance under demanding conditions.

Key Features:

• 30A rating for secure circuit protection
• High interrupting ratings: 100 Kaic at 240V, 65 Kaic at 480V, and 35 Kaic at 600Y/347V
• Fixed thermal and magnetic trip unit for consistent reliability
• Three-pole configuration for effective load management
• Compatible with 50/60 Hz systems and supports line and load connections

This molded case circuit breaker ensures reliable and durable protection for a variety of electrical applications.

Documents:

Aplication notes
Application of Tap Rules to Molded Case Breaker Terminals
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
StrandAble terminals product aid
