EGH3015FFG - Eaton Series G Molded Case Circuit Breaker

The Eaton Series G Molded Case Circuit Breaker is designed to deliver premium protection for critical electrical systems. With a 15A current rating and a three-pole configuration, it features a fixed thermal and fixed magnetic trip unit to ensure reliable overload and short-circuit protection. Built for systems rated up to 600Y/347V AC, it offers exceptional interrupting capacities of 100 Kaic at 240V AC, 65 Kaic at 480V AC, and 35 Kaic at 600Y/347V AC. Supporting both line and load terminal connections and operating at 50/60 Hz, this breaker is ideal for high-demand industrial and commercial applications.

Key Features:

• 15A rating for precise circuit protection
• High interrupting ratings: 100 Kaic at 240V, 65 Kaic at 480V, and 35 Kaic at 600Y/347V
• Fixed thermal and magnetic trip unit for dependable performance
• Three-pole design for enhanced load distribution
• Compatible with 50/60 Hz systems with line and load connections

This molded case circuit breaker ensures high-level safety and performance for demanding electrical environments.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
High performance operating handles for Series G circuit breakers product aid
