EGE3100FFG - Eaton Series G Molded Case Circuit Breaker

The Eaton Series G Molded Case Circuit Breaker is engineered to deliver strong and reliable protection for commercial and industrial electrical systems. Featuring a 100A current rating and three-pole configuration, it comes with a fixed thermal and fixed magnetic trip unit for dependable overload and short-circuit protection. Designed for use in systems rated up to 600Y/347V AC, it offers excellent interrupting capacities of 35 Kaic at 240V AC, 25 Kaic at 480V AC, and 18 Kaic at 600Y/347V AC. With line and load terminal connections and 50/60 Hz frequency compatibility, this breaker ensures safe and efficient performance.

Key Features:

• 100A rating for reliable, high-capacity circuit protection
• Fixed thermal and magnetic trip unit for consistent operation
• Interrupting ratings: 35 Kaic at 240V, 25 Kaic at 480V, and 18 Kaic at 600Y/347V
• Three-pole design for balanced load distribution
• Suitable for 50/60 Hz systems with line and load terminals

This molded case circuit breaker delivers powerful and consistent protection for heavy-duty electrical applications.

Documents:

Application notes
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Series G MCCB quick selector

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Specifications and datasheets
MOEM MCCB product selection guide
