EGE3080FFG - Eaton Series G Molded Case Circuit Breaker

The Eaton Series G Molded Case Circuit Breaker provides robust and dependable protection for industrial and commercial electrical systems. With an 80A current rating and a three-pole configuration, it features a fixed thermal and fixed magnetic trip unit for consistent overload and short-circuit protection. Rated for 600Y/347V AC systems, it offers strong interrupting capacities of 35 Kaic at 240V AC, 25 Kaic at 480V AC, and 18 Kaic at 600Y/347V AC. Designed for use with line and load connections and operating at 50/60 Hz, this breaker ensures efficient performance in demanding environments.

Key Features:

• 80A rating for heavy-duty circuit protection
• Fixed thermal and magnetic trip unit for consistent reliability
• Interrupting ratings of 35 Kaic at 240V, 25 Kaic at 480V, and 18 Kaic at 600Y/347V
• Three-pole design ideal for industrial applications
• Compatible with 50/60 Hz systems and supports line and load connections

This molded case circuit breaker offers reliable and durable protection for high-demand electrical installations.

Documents:

Application notes
Application of Tap Rules to Molded Case Breaker Terminals
Application of Multi-Wire Terminals for Molded Case Circuit Breakers

Brochures
Motor protection circuit breakers product aid

Catalogs
Circuit Protection, Molded Case Circuit Breakers, Volume 4, Tab 2

Specifications and datasheets
Eaton Specification Sheet - EGE3080FFG
