Deka DD-HIM-TAB Set-Up Tablet for Deka Duration Drop-In
Deka Duration T-Monitor Battery Display Interface
The Deka DD-HIM-TAB (T-Monitor) is an advanced display interface designed for use with Deka Duration LiFePO4 monobloc batteries. It provides real-time system visibility, allowing users to monitor critical battery performance data through an intuitive 5-inch touchscreen display.
Using RS485 communication, the T-Monitor delivers accurate system information including voltage, current, remaining capacity, temperature, and system configuration. It can be connected directly to the battery or integrated through the Deka Duration T-BOX for expanded system communication.
Key Features
- 5.0-inch IPS LCD touch screen with 800×480 resolution and 262K color display
- RS485 communication for real-time battery data
- Displays voltage, current, remaining capacity (Ah), temperature, SOC %, and power (W)
- Protective outer shell with UV resistance
- IP65 front panel protection rating
- Built-in speaker, LED light, and light-sensing (photosensitive) sensor
- Audible alarm for system warnings (low SOC, over/under voltage, temperature alerts)
- Compatible with multiple inverter protocols (Victron, SMA, Sol-Ark, Schneider, Growatt, Deye, and more)
- Direct connection to battery or via T-BOX communication hub
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Input Voltage | 9–60V DC |
| Rated Power | <5W |
| Operating Current (Max) | 170mA @ 12V |
| Operating Current (Min) | 55mA @ 12V |
| Display Resolution | 800 × 480 |
| Screen Size | 5 Inch IPS LCD |
| Communication Protocol | RS485 |
| Protective Level | IP65 (Front Panel) |
| Operating Temperature | -4°F to 158°F (-20°C to 70°C) |
| Storage Temperature | -22°F to 176°F (-30°C to 80°C) |
| Operating Humidity | 10%–90% RH |
| Net Weight | 0.75 lbs (340g) |
| SKU | DD-HIM-TAB |
Compatible Inverter Protocols
- Protocol 1: Victron / SMA / Studer Innotec / Sofar
- Protocol 2: Sol-Ark / Solis / Goodwe / Deye / Growatt / SAJ / LUXPOWER / Megarevo / INVT / Sermatec / TBB / MUST / SUNGOLDPOWER SG / Sunsynk
- Protocol 3: Schneider
- Protocol 11: Voltronic / SUNGOLDPOWER SPH / RCT / MPP / Alpha Outback / Phocos
What's Included
- 1x DD-T-MON 5.0-inch IPS LCD Touch Screen Monitor with mounting bracket
- 1x Power and Communication Cable (connects to battery or T-BOX)
Warranty
Manufactured by MK Battery (East Penn Manufacturing). Please contact MK Battery for warranty details: Toll Free: 800-372-9253 | Email: sales@mkbattery.com | Website: www.mkbattery.com
