CSR2150N - Eaton Type CSR Standard Circuit Breaker

The Eaton Type CSR Standard Circuit Breaker is a high-performance, two-pole breaker designed for residential and light commercial electrical systems. Rated for 150 A, it offers reliable protection with a short-circuit current rating (SCCR) of 25 kAIC. This circuit breaker is suitable for use in single-phase 120/240 V systems and can accommodate wire sizes ranging from 2 AWG to 300 KCMIL. It is specifically designed for use in Type ECC unit enclosures, ensuring compatibility and safety in electrical installations.

Key Features:

• 150 A rating for reliable circuit protection
• 25 kAIC short-circuit current rating for enhanced safety
• Two-pole design for single-phase 120/240 V systems
• Supports wire sizes from 2 AWG to 300 KCMIL
• Ideal for use in Type ECC unit enclosures

This Eaton Type CSR Standard Circuit Breaker provides dependable and efficient protection for your electrical systems.

Documents:

Catalogs
Residential and Light Commercial, Loadcenters and Circuit Breakers, Volume 1 Tab 1

Specifications and datasheets
Eaton Specification Sheet - CSR2150N
