CCV2200X - Circuit Breaker

The Circuit Breaker is a crucial component for electrical systems, providing overcurrent protection in a variety of applications. Designed for 120/240 V AC systems, this 200 A breaker offers reliability and efficiency with a compact size and versatile wiring capacity. It supports wire sizes ranging from 2/0 AWG to 300 Kcmil, making it suitable for diverse electrical setups. The breaker features a two-pole, single-phase design, ensuring it can handle both residential and light commercial loads. Its overall dimensions of 5.4 inches in height, 7.7 inches in length, and 4.5 inches in width make it an ideal fit for many standard panelboards.

Key Features:

• Type: Circuit Breaker
• Amperage: 200 A
• Voltage Rating: 120/240 V AC
• Poles: 2
• Phase: 1
• Wire Size Range: 2/0 AWG to 300 Kcmil
• Overall Dimensions: 5.4 in height, 7.7 in length, 4.5 in width
• Weight: 2.83 LB
• Design: CCV Breaker

This circuit breaker is an essential part of your electrical setup, offering robust protection against overloads and short circuits, ensuring the safety and stability of your electrical system.

Documents:

Catalogs
Residential and Light Commercial, Loadcenters and Circuit Breakers, Volume 1 Tab 1

Specifications and datasheets
Eaton Specification Sheet - CCV2200X
