BRX2100 - Standard Trip Circuit Breaker

The Standard Trip Circuit Breaker, 100 A, is designed to provide reliable overcurrent protection for electrical circuits. With a common tripping mechanism and a plug-on installation, this breaker is ideal for 120/240 V AC systems. It features line and load lug terminals for easy connection, ensuring secure electrical operation. The compact design offers an overall height of 2.938 inches, a length of 2.48 inches, and a width of 2 inches, making it a space-efficient solution for various applications.

Key Features:

• Amperage Rating: 100 A
• Voltage Rating: 120/240 V AC
• Mounting Type: Plug-on
• Terminal Type: Line and Load Lug
• Overall Height: 2.938 in
• Overall Length: 2.48 in
• Overall Width: 2 in
• Tripping Mechanism: Common Trip
• UL Listed for safety and reliability

This circuit breaker offers dependable protection, ensuring your electrical systems remain safe and functional under varying load conditions.

Documents:

Specifications and datasheets
Eaton Specification Sheet - BRX2100

Warranty guides
Eaton type BR circuit breaker limited warranty June 2024
