BRSN220 - Eaton BR Thermal Magnetic Circuit Breaker

The Eaton BR Thermal Magnetic Circuit Breaker is a dependable solution designed to protect electrical circuits within residential and light commercial applications. This Type BR 1-Inch Switching Neutral Breaker features a 20-ampere rating and delivers effective protection with thermal magnetic trip technology, helping to guard against both overloads and short circuits. The integrated switching neutral function enhances safety by disconnecting both the hot and neutral wires when tripped, ideal for sensitive electronic circuits or AFCI/GFCI applications.

Key Features:

• Breaker Type: Thermal Magnetic, Switching Neutral
• Type: Type BR, 1-Inch Plug-On
• Current Rating: 20 A
• Voltage Rating: 120V
• Interrupting Rating: 10 kAIC
• Poles: Two-Pole, providing complete circuit disconnection
• Wire Range: Accepts 14–4 AWG Copper/Aluminum wires
• Compatibility: Designed for Eaton Type BR Loadcenters
• Mounting: Plug-on style for easy installation

This Eaton BR Switching Neutral Breaker is ideal for applications requiring enhanced safety and is compliant with modern electrical codes. It offers a reliable and straightforward solution for protecting circuits while also improving system integrity with its neutral disconnect capability

Documents:

Catalogs
Residential and Light Commercial, Loadcenters and Circuit Breakers, Volume 1 Tab 1

Specifications and datasheets
Eaton Specification Sheet - BRSN220

Warranty guides
Eaton type BR circuit breaker limited warranty June 2024
