Victron Phoenix Inverter Compact 24V/1600VA/230V

The Inverter Smart is an efficient and reliable inverter. Built on our proven and field tested inverter platform, it now comes with a new slimmer design and full metal casing. Models are available in 1600VA, 2000VA, 3000VA and 5000VA for 12, 24 or 48V systems. It's powerful enough to supply most common plug in appliances in your car, boat, caravan or home. A toroidal transformer provides a high peak power surge capacity, stable voltage, frequency and high quality sine-wave. Installation is simpler than ever before with terminals now more accessible for the installer, enabling a more professional finish. Bluetooth is built-in, and makes setting up your high power inverter easier than ever before. Configure alarms, alarm relay, voltage cut-off, output voltage, frequency, eco-mode and more, all from within VictronConnect.

Feature Bullets

• Bluetooth built-in: fully configurable with a tablet or smartphone - Low battery voltage alarm, low battery voltage cut-off and restart levels, dynamic cut-off: load dependent cut-off level, output voltage: 210 - 245 V, frequency: 50 Hz or 60 Hz, eco mode on/off and eco mode sense level, alarm relay
• Monitoring: In- and output voltage, load and alarms
• VE.Direct communication port - The VE.Direct port can be connected to a computer (VE.Direct to USB interface cable needed) to configure and monitor the same parameters
• Proven reliability - The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverters are short circuit proof and protected against overheating, whether due to overload or high ambient temperature
• High start-up power - Needed to start loads such as power converters for LED lamps, halogen lamps or electric tools
• ECO mode - When in ECO mode, the inverter will switch to standby when the load decreases below a preset value. Once in standby the inverter will switch on for a short period every 2,5 seconds (adjustable). If the load exceeds the preset level, the inverter will remain on
• Remote on/off - A remote on/off switch or relay contact can be connected to a two pole connector. Alternatively, the H terminal (left) of the two pole connector can be switched to battery plus, or the L terminal (right) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example)
• LED diagnosis
• To transfer the load to another AC source: the automatic transfer switch - For our low power inverters we recommend our Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Alternatively use a MultiPlus with built-in transfer switch
• Inverter Control - This panel is intended for remote on/off control of all Inverters Smart units
• Color Control GX and other GX devices - Provides monitoring and control. Locally, and remotely on the VRM Portal
• VE.Direct to USB interface - Connects to a USB port
• Bluetooth wireless communication - Connects to a smart phone (both iOS and Android)
• BMV-712 Smart Battery Monitor - The BMV Battery Monitor features an advanced microprocessor control system combined with high resolution measuring systems for battery voltage and charge/discharge current. Besides this, the software includes complex calculation algorithms, like Peukert's formula, to exactly determine the state of charge of the battery. The BMV selectively displays battery voltage, current, consumed Ah or time to go. The monitor also stores a host of data regarding performance and use of the battery
• VE.Direct communication port - For remote monitoring and system integration
• Bluetooth wireless communication - For remote monitoring and system integration

Specifications:

Dimensions: 485 mm Height x 219 mm Width x 125 mm Depth
Material: Steel
Color: Blue (RAL 5012)
Continuous Power at 25 deg C: 1600 VA/1300 W - (Inverter)
Continuous Power at 40 deg C: 1200 W - (Inverter)
Continuous Power at 65 deg C: 800 W - (Inverter)
Peak Power: 3000 W - (Inverter)
DC Input Voltage: 18.6-34 V - (Inverter)
Output AC Voltage: 230 VAC +/-3% - (Inverter)
Output AC Frequency: 50/60 Hz +/-0.1% - (Inverter)
Dynamic (Load Dependent) DC Low Shut Down (Fully Configurable): Dynamic Cut-Off
Maximum Efficiency: 94% - (Inverter)
Zero-Load Power: 9 W - (Inverter)
Zero-Load Power in ECO Mode: 1.3 W - (Inverter)
Protection: A-G
Battery Connection: M8 Bolts
Protection Category: IP21
Operating Temperature: -40 to 65 deg C
Humidity: Maximum 95% (Non-Condensing)
Remote On/Off: Yes
Automatic Transfer Switch: Filax
Parallel 3-Phase & Split-Phase Operation: No
Programmable Relay: Yes
120 VAC/230 VAC-Connection: Screw Terminals
Cooling: Fan Assisted
Standards: Safety: EN 60335-1, Emission Immunity: EN 55014-1/EN 55014-2/EN-IEC 61000-6-1/EN-IEC 61000-6-2/EN-IEC 61000-6-3, Automative Directive: ECE R10-5
Warranty: 5 Years Limited
Weight: 12 kg
