Victron Energy, LYN034160310, Lynx Smart BMS 500 NG (M10)

Victron Energy Lynx Distributor (LYN034160310) – Smart Modular DC Distribution System

The Victron Lynx Distributor is a professional-grade modular DC distribution unit designed for clean, safe, and intelligent energy systems. It forms part of the Victron Lynx modular busbar system, ideal for lithium battery banks, off-grid solar systems, and advanced power installations.

Key Features:

Fused DC Busbar: Offers four separately fused connections for distributing power to various DC components safely.

Real-Time Monitoring: Integrated with fuse status indication (LEDs) to instantly alert users to blown fuses—no guesswork required.

Modular Design: Seamlessly integrates with other Victron Lynx components (e.g., Lynx Power In, Lynx Smart BMS, Lynx Shunt) to build scalable energy storage systems.

Heavy-Duty Build: Industrial-grade design with solid copper busbars ensures low resistance and high current capacity—up to 1000A total.

Easy Installation: Pre-installed M8 studs and included covers simplify connection and improve safety compliance.

Technical Specifications:

Part Number: LYN034160310

Fused Outputs: 4 x M8 connections (fuses not included)

Fuse Monitoring: LED indicators (12/24/48V compatible)

Maximum Current: 1000A continuous (250A per output recommended)

Dimensions: 190 x 180 x 80 mm

Weight: 2.2 kg

Ideal For:

Lithium and AGM/DC systems

Marine, RV, and industrial applications

Solar and backup power installations

Why Victron?

Victron Energy products are trusted worldwide for their reliability and innovation. The Lynx Distributor ensures both safety and performance in any DC power distribution setup.
