HomeGrid Stack'd Series LFP Batteries - 2 Stack of Batteries

With the highest output and capacity range available, the Stack'd Series battery is the right solution for residential and small commercial storage projects. From small off-grid cabins, to peak rate TOU (time-of-use) offset, family homes in suburbia, and small commercial projects, the HomeGrid Stack'd Series battery is the proven best choice.

Feature Bullets

• High Capacity 38.4 kWh - Up to 15 units in parallel
• High power - 14.4 kW
• Live Communications - Real time display, mobile access, established closed-loop communications
• Modular Design - Each module has a capacity of 4.8 kWh, with each Stack supporting 2-8 modules

Specifications:

Series/Model: STACK'D
Number of Modules: 2
Capacity: 9.6 kWh
Power Rating: 8.6 kW
Surge (10 s): 14.4 kW
Battery Chemistry: Lithium Iron Phosphate
Battery Capacity (Ah): 200 Ah
Nominal DC Voltage: 48 V
DC Voltage Range: 46-56 V
Maximum Charge Current: 180 A
Maximum Discharge Current: 180 A
Maximum Pulse Current DC: 300 A for 10 sec
Charge Temperature: 32-113 deg F
Discharge Temperature: 14-140 deg F
Enclosure Rating: IP55/NEMA 3R
Mounting Type: Floor Standing
Communication: CAN/RS485
Efficiency: >98%
Scalability: 15 Units in Parallel (576 kWh)
Compatible Inverters: Sol-Ark, Schneider, SMA, Victron, Outback
Battery Module Start Heating Temperature: 37.4 deg F
Battery Module Stop Heating Temperature: 42.8 deg F
Battery Module Heating Power: 150 W
Standards: UL 1642, UL 1973, UN 38.3, UL 9540, UL 9540a, CEC, SGIP, OGPe
Dimensions: 29 in x 15.75 in x 25.25 in
Weight: 304 lb
